How to maintain the chiller of AEONLaser

Overview

In this guide, you will learn how to perform proper maintenance on the MIRA S chiller.

Frequency of water change

Every 3-5 Months (depend on how frequently you use the machine and the working environment)

Selection of water

• Distilled Water
• Purified Water
• Reverse Osmosis Water

Do not use Mineral water

Adding Water

1. Unplug the machine from the wall outlet
2. Place a bucket under the Water Outlet
3. Unscrew the Water Outlet cap and allow the water to drain into the bucket. If the water flow seems slow, remove the Water Inlet cap
4. Once the water has fully drained, screw the Water Outlet cap back into place
5. Unscrew the Water Inlet cap
6. Using a funnel, fill the Chiller with distilled water until it to the “Green” section on the fill gauge

7. Screw the cap back on to the Water Inlet


After adding Water

1. Turn on the machine and let in run
2. Let the water circulates and fills the glass tube and observe the glass tube, if you find contaminants or impurities, you can press the button on this hose to disconnect the hose
3. Don't worry that the water will flow out, because they are one way valves, then cut this zip tie, disconnect this joint and the hose, let the water flush out the contaminants or impurities
4. Then power off the machine, reconnect the hose with the zip tie
5. Finally, add the distilled water to the “Green” section on the fill gauge when the machine is powered off

CAUTION: the water level in the chiller MUST NOT BE LOWER than the "RED" section, otherwise, it will DAMAGE the chiller.
