Overview
What you will learn
In this guide, you will learn how to handle a remote control on your AEONLaser, allowing you to operate the machine remotely.
When to do this
Moving the laser head | Focusing | Framing | Pulsing | Testing | Start & Stop batch Processing | After-Sales Maintenance | Debugging and other scenarios.
What you need
- A Remote Controller kit
- A Machine Panel Key
- An Allen Key
- A Screwdriver
- A Plier
- Two Batteries
Video
Please ensure that the machine is turned off during the following steps
Steps
NOVA Redline series
- Open this panel, you will see the green terminal connector, which is where the remote cable goes.
- Before unplugging it, note the wire color order from right to left. The sequence is red | yellow | white | black. Then unplug the green connector.
-
Connect the wires from the terminal of the remote control to the terminals of NOVA in the same color order.
- Use a screwdriver to loosen the screws on the terminal block and remove the existing wires. The red wire on this cable is a bit too long. Using pliers to trim it to match the length of the other three wires. Then insert the wires into the connector in this order red | yellow | white | black and tighten the screws.
- Next, take the green end of the cable and connect it to the antenna cable, attach the antenna to the cable, then attach the antenna to the cable.
- Now, reconnect the green terminal block back into the machine. The bottom of the antenna is magnetic. Place the antenna as high and as exposed as possible on the machine so the signal reception will stronger and more stable. Now, reconnect the green terminal block back into the machine.
- Install batteries into the remote controller, turn on the machine and the remote will be ready to use.
MIRA S series
- Open the side panel, grab the cover, press it down and pull it backwards, you will see a green terminal block, this is where the remote cable connects.
-
The following steps are the same as those of NOVA Redline.
